5780kg 36kw 2100rpm Excavator Construction Equipment

EXCAVATOR

Product highlights

Isuzu high-power engine has sufficient power reserve, which can ensure the reliability of the machine in bad working conditions;

The bottom of the reinforced rock bucket adopts wear-resistant steel plate, which makes the strength of the bucket higher;

The shape of the second arc is optimized to reduce the resistance and wear of the sand to the bucket body, which is more labor-saving and durable;

Suspension seat, excellent shock absorption and noise reduction performance, air conditioning, three-dimensional air, so that the driver has a comfortable experience;

Adopt large area cover opening mode, stand on the ground for daily maintenance after opening, convenient maintenance and good accessibility;

A complete hydraulic buffer system can reduce the internal impact of the hydraulic system;

After market verification, the stability of the whole machine is guaranteed, and the product life is greatly improved;

Strength rotary platform, D-shaped large section edge beam, more firm, can resist stronger external impact, enhance the overall sense of heaviness.

Specification:

total weight: 5780kg, bucket capacity: 0.1 ~ 0.28m3

Engine model: 4JG1 rated power: 36kw / 2100rpm

Large torque: 175nm / 1800rpm displacement: 3.059l

Performance: gradeability: 70% (35 °) slewing speed: 9.6rpm

Ground specific pressure: 32.75kpa bucket digging force: 45KN

Digging force of stick: 33kn traveling speed: 3.73/2.4km/h

Standard track of traveling part: 400mm carrier chain wheel each side: 1

Number of track shoes: 40 each side of roller: 5

Oil and coolant capacity final drive: 2 × 0.9l fuel tank: 130L

Hydraulic tank: 85L engine oil: 9.6l

Radiator 6.5l
