1700kg Mini Crawler Crane

Micro crawler crane(spider crane)

Specification:

1.95t × 1.75m

Maximum operation radius 5.86m × 0.20t

Maximum ground lift 6.65mx0.55t

Maximum underground lift 10mx1t 20mx1t 40mx0.74t lifting hook lifting speed 0-8m / min

Specification of steel wire rope: Φ 8mm × 50m

Angle / time of boom of rolling device 0-70 ° / 20sec

Track (length × width) 1045mm × 180mm

Specific voltage of grounding 44kpa (0.45 kgf / cm2)

Diesel engine

Type / displacement single cylinder air cooling / 0.441l rated power 8kw / 3600min-1 starting mode electric starting performance - 5 ° C ~ 40 ° C

Fuel / volume Diesel / 5L battery capacity 12V 45ah fuel consumption rate 240g / kw-h noise level rated speed ≤ 80dB (a) (7m)

Wireless remote control and manual operation features, full proportional control and manual proportional control

Vehicle size: length × width × height 2200mm × 600mm × 1600mm

Main engine of vehicle weight: 1700kg standard configuration: manual and wireless proportional remote control (double operation mode), display screen, moment limiter, over winding alarm and automatic stop device, three circle alarm and automatic stop device, automatic hook retracting device, working condition of outrigger, alarm and automatic stop device of outrigger off the ground (or 3-degree inclination of vehicle body), wire rope rope pressure device, three color light, remote control light, walking/ Three mode interlocking system for outrigger / boom
