Tower Crane Integrated Core Drill Rig For Large Angle Inclined Hole Drilling

Tower Crane Integrated Core Drill Rig For Large Angle Inclined Hole Drilling

Tower Crane Integrated Core Drill Rig For Large Angle Inclined Hole Drilling
Tower Crane Integrated Core Drill Rig For Large Angle Inclined Hole Drilling

Large Image :  Tower Crane Integrated Core Drill Rig For Large Angle Inclined Hole Drilling Get Best Price

Product Details:

Place of Origin: TIANJIN ,CHINA
Brand Name: COMMAND
Certification: ISO
Model Number: CDLYX

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Price: Negotiation
Packaging Details: 40 FR OR BULK CARGO SHIP OR RO RO SHIP
Delivery Time: 35days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10+SET+per35DAYS
Detailed Product Description
High Light:

Tower Crane Integrated Core Drill Rig

,

700m long hole drill rig

,

1000m long hole drill rig

HIGH EFFICIENCY CRAWLER CORE DRILL





XY-44T tower crane integrated core exploration drilling rig is a drilling equipment integrating XY-44 drilling rig and rod drilling tower. The tower body of the rig has a lifting function, the structure is simple and reasonable, the weight of the rig is light, and the operation is convenient. The rig tower has a large adjustment angle and flexible operation, and is particularly suitable for large-angle inclined hole drilling.



(Drilling capacity) Φ43mm 1000m
Φ50mm 700m



(Rotary head)

(Direct rotary speed) 135~1588 r/min
(Reverse rotary speed) 110;338 r/min
(Feeding stroke) 600mm
(Lifting capacity) 72kN
(Feeding capacity) 54kN
(1nsidediameterofspindle) Φ68mm



(Hoist)

(lifting speed,3th layer) 1.09;2.02;2.89;4.18m/s
(lifting capacity, single line) 30KN



(Hydraulic moving system of chassis)

(Stroke) 400mm
(Distance between machine and bole hole) 250mm



(Power unit)

Y225S-4,37kW

(Electric motor Model Y225S-4)

1480r/min

ZH4100P,40kW

(Diesel engine Model ZH4100P)

2000r/min
(Dimension) 2640×1100×1750 mm

Weight(Without power unit)



1670kg
